Secondary injection moulding process. Ensure good probe sealing and dimensional stability. Eddy current displacement sensor has good long-term reliability, high sensitivity, strong anti-interference ability, non-contact measurement, fast response, and is not affected by oil and water. It is often used for long-term real-time monitoring of parameters such as axle displacement, axle vibration and axle speed of large rotating machinery. It can analyze the working condition and fault reasons of the equipment. Effective protection and pre-maintenance of equipment. Specifications Resolution: 0.05% Temperature Drift: ≤0.05%/°C Power Supply: -18~-24VDC (Negative Voltage Output) 18~ 30VDC (4~20mA Current Output) Frequency Response: 0~10000Hz Amplitude and Frequency Features: 0~1kHz Attenuation is less 1% 1~10kHz Attenuation is less 5% Phase and Frequency Features: 0~1kHz Phase <-10° 10kHz Phase <-100° Environment and Physical Specifications Temperature Range: Probe – 50°C~ 175°C Adapter: -50°C~ 120°C Maximum Working Pressure of Probe: 12Mpa Working Medium: Air, Oil and Water Protection Level: IP68 Shell Material: Stainless Steel Installation Method: Guide Rail Installation Sensitivities DiameterOutput Ø5 Ø8 Ø11 Ø25 Ø50 Negative Voltage Output (V/mm) 8 8 4 0.8 0.4 Current Output (mA/mm) 16 8 4 1.33 0.64 Order Parameters: 1) Probe Order Model: ZD220-TD-A[ ][ ]-B[ ]-C[ ]-D[ ][ ][ ]-E[ ][ ]-F[ ][ ]-G[ ][ ] (K) A – Probe Diameter B – Thread C – Install D – Total Length E- Length of No Thread F – Cable Length (K) 05: Ø5 1: M8×1 1: Standard 020: 20mm 00: 0mm 05: 5m K: Armored Cable 08: Ø8 2: M10×1 2: Direction 050: 50mm 01: 2mm 09: 9m Empty No Armored Cable 11: Ø11 3: M14×1.5 3: Side Cable 250: 250mm 05: 5mm 25: Ø25 4: M30×2 4: Flange Mounting … … 10: 10mm 50: Ø50 5: 1/4-28 … … 6: 3/8-24 7: 1/2-20 8: 5/4-12 Example: ZD220-TD-08-1-1-50-00-05 (K) Parameters: (Probe Diameter Ø8, Thread M8×1, Standard Installation, Total Length 50mm, Length of No Thread 0, Cable Length 5m with Armored 2) Adapter Order Model: ZD220-QZ-A[ ][ ]-B[ ][ ] A Range B Output Mode 01: 1mm 01: 0 ~ 5V 05: 4 ~ 20mA 02: 2mm 02: 0 ~ 10V 06: 2 ~ 18V 03: 3mm 03: -2 ~ -18V 07: 1 ~ 5V 04: 4mm 04: -4 ~ -20V 08: 1 ~ 10V …
