Features: ● Low-frequency, low vibration level vibration measurement ● High charge sensitivity ● Memory ring, shear structure ● Passive, positive piezoelectric effect Specifications: Axial Sensitivity 10000pC/g Transverse Sensitivity ≤5 % Frequency Response（Refer to the Frequency curve）5% 0.2 ～500 Hz Mounting Resonance Frequency 4,500 Hz Temperature Response Refer to the temp. curve Polarity Positive Insulation Resistance ＞109 Ω Capacitance ～46000 Pf Operating Temp. Range -40～ 120 ℃ Range 10g Thermal Transient Sensitivity 30mg/℃(0.3Hz) Magnetic Sensitivity 2g/T（50Hz，0.03T） Base Strain Sensitivity 0.5g/με Weight 300g Case Material Stainless steel Mounting Method M8 Sensing Element PZT-5 Structural Design Memory ring, shear Output Side L6 Accessories: Sensor Certificate Calibration parameter, frequency response curve M8、M5/M8 bolt Respective one 2m, L6/ L5 STYV-1 one
